CXD8 CXD8-CDX DAYLIGHT SIGNAL LIGHT/ CHARGER
The scope of application
Applied to daylight signal communication between the ships.
Products characteristic
1.With good quality cast aluminum shell and mechanical flash device.
2.Light, convenient to operate and bring.
Production authentication
The product approved by the CCS( China Classification Society)
Adopt standard
Conform to MS.C.95(72) DECISION and JISF8456-1996.
Details



电压Voltage:24V

功率Power:60 W

光柱角 Light pillar angle:6°

光强:Light intensity: 60,000cd

望远镜倍率 Telescope magnification: 4

望远镜视角Telescope visual angle: 3°

可见距离Visibility: 2n.m

灯座Lamp holder: G6.35

插座Plug: 25M-4A 四插 Four Pins

防护等级 Protection class: IP44

电缆外径 Cable outside diameter: Φ9.5

重量 weight:2.6 KG

CXD8-CDX 充电器 Charger

输入 Input: AC110V/60Hz, AC220V/50Hz/60Hz

输出 Output: AC24V, AC12V/DC24V, DC12V

容量 Capacity: 7Ah

使用温度 Temperature: -25-45

插座Socket: 25M-4B 四插座Four pins, 25M-3B 三插 Three pins

防护等级 Protection class:IP56

重量 weight:3.6kg

订货时请注明电压和频率 Mark the voltage and frequency when order
